The PAR9X12B-IP is a mid-sized outdoor rated battery fixture, featuring 9 x 12W RGBWAU LEDs in a die cast aluminium housing, a 25° beam angle, WDMX on-board and IR control.
Photometrics
Light Source: 9 x 12W RGBWAU LEDs
Beam Angle: 25°
LED Life: 50,000 hours
Effects
Dimming: 0~100%
Power
Input Voltages: 100V~240V AC, 50/60Hz, 72W
Power Connection: Seetronic® Outdoor True1 in/out
Battery operating time:
- 16 hours (one colour mode)
- 8 hours (colour fading mode)
Control
Operational Modes: DMX, manual, auto, sound active, master/slave, Wireless DMX, IR Remote Control
Display: OLED touch display with glass buttons
Control Protocol: DMX512, Wireless DMX (W-DMX)
DMX Channels: 6 / 10
DMX Interface: Seetronic® 5 Pin Outdoor DMX in/out
Housing
Housing Materials: Die-cast aluminium, matte black finish
IP Rating: IP65
Cooling: Fanless Cooling
Dimensions: 268 x 195 x 245mm
Weight: 4.75kg
